HC9604FKS13H Pall hydraulic filter element made in China

Product introduction:

Pall filter element is a kind of Hydraulic Filter Element which is widely used in hydraulic system
and lubrication system to filter out the metal particles and rubber impurities caused by wearing in
the oil to guarantee the normal operation of the system.

Picture show:

Product features:

1. Material: HV fiberglass, Ahistrom filter paper, stainless steel wire mesh

2. Filter accuracy: 10um

3. Pressure: 1.0Mpa, 2.0Mpa, 16.0Mpa, 21.0Mpa

4. Application field: hydraulic system, lubrication system

5. O-Ring: NBR, VITON
6. Dimension: 79*51mm
7. Life span: 5-6 months

Technical data explaination:

Model               β                      precision

   Z               β2.5≥1000                    1

   P               β5≥1000                       3

   N               β7≥1000                       6

   S               β12≥1000                    10

   T               β22≥1000                     25


Products application:

1.Thermal power and the nuclear: turbo-generator, boiler lubrication system, speed control system, bypass
   control system of the purification of the oil, water pump, fan and dust removal system purification.
2.Mechanical processing equipment: papermaking machinery, mining machinery, the injection molding mac-
   hine and large precision machinery lubrication system and compressed air purification.
3.Railway internal combustion engines and generators: lubricating oil and oil filter.
4.Automobile engine and engineering machinery: internal combustion engine with air filter, oil filter, fuel filter,
   engineering machinery, the ships, the vehicles to use all kinds of hydraulic oil filter, diesel oil filter, water filter.
5.All kinds of lifting, handling homework: lifting, loading and other construction machinery to fire, maintenance,
   handling special vehicle, ship's cargo crane, anchor machine, etc.
