CFF suction oil filter for hydraulic oil filtration

Product introduction:

1.Leemin CFF Tank Mounted Magnetic Suction Oil Filter carries by-hand sealing valve which should
   be closed when exchanging element and the oil won't flow out.
2.The filter should be installed under the oil surface. The filter has blocked indicator which will make signals
   when the element is blocked and the vacuum index reaches 0.018Mpa, then the element will be changed
   in time so as to avoid the breakdown.

Picture show:

Product features:

1. Flow rate: 120-630L/min

2. Filter precision: 80-180um
3. DN: 25-100mm
4. Connecting way: Flange
5. Element model: FFAX, FX

Quality assurance:

ISO 2941------Collapse & Burst Resistant

ISO 2942------Fabrication & Integrity Test

ISO 2943------Material Compatibility with Fluids

ISO 3724------Flow Fatigue Characteristics

ISO 3968------Pressure Drop vs. Flow Rate

ISO 16889------Multi-pass Performance Testing


Our certificates:
